Radxa Display 4 Luna

Product Overview

The Radxa Display 4 Luna is a high-quality IPS display with touch support, designed for rapid deployment across multiple boards and scenarios.

Using a single USB Type-C cable, it carries both video and touch signals, supports extended and mirrored display modes, works plug-and-play on Linux, Windows, and macOS hosts, and is compatible with Radxa, Raspberry Pi, and other common single-board computers. Key highlights:

• 4.0-inch IPS LCD
• 720 × 720 resolution
• 5-point capacitive touchscreen
• USB Type-C connection (video + touch)
• Supports extended / mirrored display modes
• Cross-platform support (Linux / Windows / macOS)

Specifications

• Size: 4.0 inch
• Resolution: 720 × 720
• Display type: IPS
• Touch type: 5-point capacitive
• Interface: USB Type-C (video + touch)
• Display modes: Extended / Mirrored
• OS support: Linux / Windows / macOS
• Power: USB Type-C
• Enclosure (optional): MagSafe-style case
• Raspberry Pi support: Raspberry Pi 3 / 4 / 5
• Power consumption: typical < 1 W
• Brightness: 350 nits
• Viewing angle: 178° (horizontal / vertical)
• Contrast ratio: 800:1
