AOT-GAN Example

This document describes how to use the QAI AppBuilder Python API to run inference with the AOT-GAN image inpainting model on Qualcomm® Hexagon™ Processor (NPU).

Supported Devices

Device	SoC
Fogwise® AIRbox Q900	QCS9075

Install QAI AppBuilder

tip

1. Please install QAI AppBuilder according to QAI AppBuilder Installation Guide.

2. Please configure ADSP environment variables according to Create ADSP Environment Variables.

Run the Example

Install Dependencies

Device

pip3 install requests tqdm qai-hub py3_wget opencv-python torch torchvision

Run the Script

• Navigate to the example directory

  QCS9075

  Device

  cd ai-engine-direct-helper/samples/python

• Prepare input images. The following images are used as examples:



  input image



  mask image

• Run inference

  Device

  python3 aotgan/aotgan.py

  $ python3 aotgan/aotgan.py
       0.0ms [WARNING]  <W> Initializing HtpProvider

  /prj/qct/webtech_scratch20/mlg_user_admin/qaisw_source_repo/rel/qairt-2.37.1/point_release/SNPE_SRC/avante-tools/prebuilt/dsp/hexagon-sdk-5.5.5/ipc/fastrpc/rpcmem/src/rpcmem_android.c:38:dummy call to rpcmem_init, rpcmem APIs will be used from libxdsprpc
       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

     136.6ms [WARNING] Time: Read model file to memory. 21.49

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

     205.5ms [WARNING] Time: contextCreateFromBinary. 68.83

     205.6ms [WARNING] Time: UnmapViewOfFile. 0.00

     207.5ms [WARNING] Time: model_initialize aotgan 207.45

     415.4ms [WARNING] Time: model_inference aotgan 154.66

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

  /usr/bin/xdg-open: 882: www-browser: not found
  /usr/bin/xdg-open: 882: links2: not found
  /usr/bin/xdg-open: 882: elinks: not found
  /usr/bin/xdg-open: 882: links: not found
       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

  /usr/bin/xdg-open: 882: lynx: not found
  /usr/bin/xdg-open: 882: w3m: not found
  xdg-open: no method available for opening '/tmp/tmpjvwp3wzi.PNG'
  /usr/bin/xdg-open: 882: www-browser: not found
  /usr/bin/xdg-open: 882: links2: not found
  /usr/bin/xdg-open: 882: elinks: not found
  /usr/bin/xdg-open: 882: links: not found
  /prj/qct/webtech_scratch20/mlg_user_admin/qaisw_source_repo/rel/qairt-2.37.1/point_release/SNPE_SRC/avante-tools/prebuilt/dsp/hexagon-sdk-5.5.5/ipc/fastrpc/rpcmem/src/rpcmem_android.c:42:dummy call to rpcmem_deinit, rpcmem APIs will be used from libxdsprpc
     801.6ms [WARNING] Time: model_destroy aotgan 67.93

  /usr/bin/xdg-open: 882: lynx: not found
  /usr/bin/xdg-open: 882: w3m: not found
  xdg-open: no method available for opening '/tmp/tmp0z61xxdt.PNG'



  output image
