OpenPose Example

This document describes how to use the QAI AppBuilder Python API to run inference with the OpenPose pose estimation model on Qualcomm® Hexagon™ Processor (NPU).

Supported Devices

Device	SoC
Fogwise® AIRbox Q900	QCS9075

Install QAI AppBuilder

tip

1. Please install QAI AppBuilder according to QAI AppBuilder Installation Guide.

2. Please configure ADSP environment variables according to Create ADSP Environment Variables.

Run the Example

Install Dependencies

Device

pip3 install requests tqdm qai-hub py3_wget opencv-python torch torchvision matplotlib easyocr qai_hub_models transformers openai-clip

Run the Script

• Navigate to the example directory

  QCS9075

  Device

  cd ai-engine-direct-helper/samples/python

• Prepare input image. The following image is used as an example:



  input image

• Run inference

  Device

  python3 openpose/openpose.py

  $ python3 openpose/openpose.py
       0.0ms [WARNING]  <W> Initializing HtpProvider

  /prj/qct/webtech_scratch20/mlg_user_admin/qaisw_source_repo/rel/qairt-2.37.1/point_release/SNPE_SRC/avante-tools/prebuilt/dsp/hexagon-sdk-5.5.5/ipc/fastrpc/rpcmem/src/rpcmem_android.c:38:dummy call to rpcmem_init, rpcmem APIs will be used from libxdsprpc
       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

     161.4ms [WARNING] Time: Read model file to memory. 49.87

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

     214.6ms [WARNING] Time: contextCreateFromBinary. 53.04

     214.6ms [WARNING] Time: UnmapViewOfFile. 0.00

     216.5ms [WARNING] Time: model_initialize openpose 216.47

     273.6ms [WARNING] Time: model_inference openpose 24.91

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

       0.0ms [WARNING]  <W> This META does not have Alloc2 Support

  /prj/qct/webtech_scratch20/mlg_user_admin/qaisw_source_repo/rel/qairt-2.37.1/point_release/SNPE_SRC/avante-tools/prebuilt/dsp/hexagon-sdk-5.5.5/ipc/fastrpc/rpcmem/src/rpcmem_android.c:42:dummy call to rpcmem_deinit, rpcmem APIs will be used from libxdsprpc
     929.9ms [WARNING] Time: model_destroy openpose 57.19

  /usr/bin/xdg-open: 882: www-browser: not found
  /usr/bin/xdg-open: 882: links2: not found
  /usr/bin/xdg-open: 882: elinks: not found
  /usr/bin/xdg-open: 882: links: not found
  /usr/bin/xdg-open: 882: lynx: not found
  /usr/bin/xdg-open: 882: w3m: not found
  xdg-open: no method available for opening '/tmp/tmpfvxac2nz.PNG'



  output image
