VDSR Example

This document introduces how to use the CIX P1 NPU SDK to convert VDSR into a model that can run on the CIX SOC NPU.

There are four main steps:

tip

Steps 1-3 should be executed in an x86 Linux environment.

1. Download the NPU SDK and install the NOE Compiler
2. Download the model files (code and scripts)
3. Compile the model
4. Deploy the model to Orion O6

Download the NPU SDK and Install the NOE Compiler

Refer to Install NPU SDK for the installation of the NPU SDK and NOE Compiler.

Download Model Files

The CIX AI Model Hub includes all necessary files for VDSR. Please follow the instructions in Download the CIX AI Model Hub Repository and navigate to the corresponding directory.

cd ai_model_hub/models/ComputeVision/Super_Resolution/onnx_vdsr

Please confirm that the directory structure is as shown below.

.
├── cfg
│   └── onnx_vdsr_build.cfg
├── datasets
│   └── calib_dataset.npy
├── graph.json
├── inference_npu.py
├── inference_onnx.py
├── output
│   └── butterfly_comparison.png
├── ReadMe.md
└── test_data
    ├── butterfly_GT.bmp
    ├── butterfly_GT_scale_2.bmp
    ├── butterfly_GT_scale_3.bmp
    └── butterfly_GT_scale_4.bmp

Compile the Model

tip

Users do not need to compile the model from scratch; Radxa provides a precompiled vdsr.cix model (which can be downloaded using the steps below). If you use the precompiled model, you can skip the “Compile the Model” step.

wget https://modelscope.cn/models/cix/ai_model_hub_24_Q4/resolve/master/models/ComputeVision/Super_Resolution/onnx_vdsr/vdsr.cix

Prepare the ONNX Model

• Download the ONNX model

  vdsr.onnx

• Simplify the Model

  Use onnxsim to solidify the model inputs and simplify the model.

  pip3 install onnxsim onnxruntime
  onnxsim vdsr.onnx vdsr-sim.onnx --overwrite-input-shape 1,1,256,256

Compile the Model

CIX SOC NPU supports INT8 computation, and before compiling the model, we need to perform INT8 quantization using the NOE Compiler.

• Prepare the Calibration Set

  • Use the existing calibration set from datasets.

    .
    └── calibration_data.npy

  • Prepare your own calibration set.

    The test_data directory already contains several images for the calibration set.

    .
    ├── 1.jpeg
    └── 2.jpeg

    Refer to the following script to generate the calibration file.

    import sys
    import os
    import numpy as np
    import cv2
    _abs_path = os.path.join(os.getcwd(), "../../../../")
    sys.path.append(_abs_path)
    from utils.image_process import normalize_image
    from utils.tools import get_file_list
    # Get a list of images from the provided path
    images_path = "test_data"
    images_list = get_file_list(images_path)
    data = []
    for image_path in images_list:
        image_numpy = cv2.imread(image_path)
        image_numpy = cv2.resize(image_numpy, (256, 256))
        image_gray = cv2.cvtColor(image_numpy, cv2.COLOR_BGR2GRAY)
        image_ex = np.expand_dims(image_gray, 0)
        input = normalize_image(image_ex)
        data.append(input)
    # concat the data and save calib dataset
    data = np.concatenate(data, axis=0)
    np.save("datasets/calib_data_tmp.npy", data)
    print("Generate calib dataset success.")

• Quantize and Compile the Model with NOE Compiler

  • Create the quantization and compilation configuration file. Please refer to the following configuration.

    [Common]
    mode = build

    [Parser]
    model_type = onnx
    model_name = vdsr
    input_model = ./vdsr-sim.onnx
    input = input.1
    input_shape = [1,1,256,256]
    output_dir = ./out

    [Optimizer]
    metric_batch_size = 1
    dataset = numpydataset
    calibration_data = ./datasets/calib_data_tmp.npy
    calibration_batch_size = 1
    calibration_strategy_for_activation = extrema & <[Convolution]:mean>
    quantize_method_for_weight = per_channel_symmetric_full_range
    quantize_method_for_activation = per_tensor_asymmetric
    activation_bits = 8
    weight_bits = 8
    bias_bits = 32
    cast_dtypes_for_lib = True
    output_dir = ./out
    save_statistic_info=False

    [GBuilder]
    outputs=vdsr.cix
    target=X2_1204MP3
    tiling= fps

  • Compile the Model

    tip

    If you encounter the cixbuild error [E] Optimizing model failed! CUDA error: no kernel image is available for execution on the device ..., it means that the current version of torch does not support this GPU. Please completely uninstall the current version of torch and download the latest version from the torch website.

    cixbuild ./onnx_deeplab_v3_build.cfg

Model Deployment

NPU Inference

Copy the .cix format model compiled with the NOE Compiler to the Orion O6 development board for model validation.

python3 inference_npu.py --images ./test_data/ --model_path ./vdsr.cix

(.venv) radxa@orion-o6:~/NOE/ai_model_hub/models/ComputeVision/Super_Resolution/onnx_vdsr$ time python3 inference_npu.py --images ./test_data/ --model_path ./vdsr.cix
npu: noe_init_context success
npu: noe_load_graph success
Input tensor count is 1.
Output tensor count is 1.
npu: noe_create_job success
Scale= 4
PSNR_bicubic= 20.777296489759777
PSNR_predicted= 25.375403931263882
npu: noe_clean_job success
npu: noe_unload_graph success
npu: noe_deinit_context success

real    0m2.837s
user    0m3.270s
sys     0m0.223s

Results are saved in the output_npu folder.

CPU Inference

Use the CPU to verify the correctness of the ONNX model inference, which can be run on an x86 host or on Orion O6.

python3 inference_onnx.py --images ./test_data/ --onnx_path ./deeplabv3_resnet50-sim.onnx

(.venv) radxa@orion-o6:~/NOE/ai_model_hub/models/ComputeVision/Semantic_Segmentation/onnx_deeplab_v3$ time python3 inference_onnx.py --images ./test_data/ --onnx_path ./deeplabv3_resnet50-sim.onnx
save output: onnx_ILSVRC2012_val_00004704.JPEG

real    0m7.605s
user    0m33.235s
sys     0m0.558s

Results are saved in the output_onnx folder.

It can be seen that the inference results on both NPU and CPU are consistent, but the running time is significantly reduced.

References

Paper link: Accurate Image Super-Resolution Using Very Deep Convolutional Networks
